天津YPG系列不銹鋼帶水冷壓片機

YPG系列不銹鋼帶水冷壓片機由壓輥，不銹鋼帶，破碎輥和行走系統組成，從擠出機擠出的熱熔狀態的物料被壓輥壓成1-1.5mm厚的片狀，然后片狀物料在輸送過程中用冷水噴淋到不銹鋼帶背面，持續將物料冷卻到固態，破碎成片狀物料落入料斗，注意：冷卻水溫度應≤14℃

主要特點：

*采用高質量進口鋼帶
*用純凈水冷卻，避免污染。
*高產量
*易于清機和維修
*壓片厚度可調，傳送速度可調
*具有安全保護措施及緊急狀態處理措施

YPG series stainless steel water cooling band

This series cooling belt  is composed of cooling rolls, stainless steel band conveyor, crusher and driving system. The discharged material from extruder is sheeted at thickness of 1-1.5mm by rollers .The sheeted material is transported to the crusher while being continually cooled by water which is sprayed to the underside surface of the stainless steel band. Then crushed chip material falls down to the hopper. Attention: Temperature of cooling water should be ≤14℃

Features:
* High quality imported stainless steel band
* Material cooled by clean chilled water to avoid pollution.
* High output capacity
* Easy for cleaning and maintenance
* Adjustable thickness of chips and speed of conveyor
*Safety protection device and emergency situation protection device

型號及規格specification
